Electronic Component Mounting
Detection of passage of PCB
The sensor built in the machine detects passing PCBs.You can install it anywhere you like.\nEmbedded amplifier photo sensor.
Detection of defects in capacitors
Bends above taping detected with through beam fiber optic cable.
Detection of lifting of tape feeder
Lifting in tape feeders in line can be detected by spot lasser beam.
Detection of passing condensers
The sensor built in the guide detects condensers.Embedded amplifier photo sensor.
Checking of presence of silver paste
Even a small amount of paste can be detected with a spot size of 0.5 mm in diameter.
Detection of lead frame plating
Reliable detection achieved by determination of RGB color component and brightness.
Checking for upside-down electronic components
Blue light fiber optic sensor used for checking whether the right sides of electronic components are facing up in part chute.
PCB detection
Ultra thin sensor allowing to conserve installation space.
Color check of lighting LEDs
Discriminates lighting LED colors in the production processes for LED blinkers, tail lamps, and stop lamps.
Counting of minimal parts
Wide area fiber optic cable allowing wide-view detection.
Electronic component detection
Molded parts detected with background suppression photo sensor unaffected by color variation.
- Background suppression photo sensor DL-S10R
- BGS/FGS Switchable Sensor DLN Series (Infrared LED type)
Positioning of hybrid snbstrates
High precision positioning achieved with micro-spot laser beam.
Detecting ICs floating loose on a pallet
Due to the coaxial alignment of the light emitter and sensor, even slight positional misplacements are stably detected.
Mixing different lighting types,lighting check
Example of using both CS-R85 and CST-R85 for lighting check in the mixtures of different product types, as well as for lighting characteristics assessment.
